SMPS 12V 10A
- High efficiency
- Low temperature
- LED indicator for power on
- Over Load and Short Circuit Protection
- Over Voltage Protection
- 2x different power outputs
- DC Voltage: 24V
- Rated Current: 20A
- Current Range: 0-20A
- Rated Power: 480W
- Voltage Range: Rated +/- 15%
- Frequency Range: 47-63Hz
- Efficiency: 74%
- AC Current: 6.5A/115V 4A/230V
- Leakage Current: < 3.5mA/240VAC
- Inrush Current: 25A/115V 50A/230V
- Over Voltage Protection: 13.8-16.2V
- Working Temperature & Humidity: -10℃～+50℃，20%～90%RH
- Storage Temperature & Humidity: -20℃～+85℃,10%～95%%RH
- Temperature Coefficient: ±0.03%℃(0～50℃)
- Vibration: 10～500Hz, 2G 10min/1cycle, 60min along each axes
- L, N: AC Power Input
- V+: DC Power Output “+”
- V-: DC Power Output “-“
- GND: DC Power Output “-“
- +V / ADJ: Adjust the Output Voltage
- Powerful 24v 480w 20A max Current Draw.
- Industrial motor Drive, 3D printing applicaiton.
- Power Supply For LED, SMD, LED Strip, RGB LED Strip
- CCTV Cameras Supply
- LCD monitor, digital products and instruments kind of light accessory products
- Mechanical and electrical equipment, security, air purifier
